| Werkstoff Gehäuse | PA-reinforced | ||
| Werkstoff-Hinweis | RoHS-compliant | ||
| Switching logic for inputs | PNP (positive switching) | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Korrosionsbeständigkeitsklasse KBK | 1 - Low corrosion stress | ||
| CE-Zeichen (siehe Konformitätserklärung) | To EU EMC Directive In accordance with EU RoHS Directive | ||
| Zulassung | RCM trademark c UL us listed (OL) | ||
| Residual ripple, load voltage | 4 Vpp | ||
| Nennbetriebsspannung DC | 24 V | ||
| Max. total current per module | 0,7 A | ||
| Betriebsspannungsbereich DC | 18 V ... 30 V | ||
| Fuse protection (short circuit) | Internal electronic fuse protection for each group |
| Werkstoff Deckel | PA-reinforced | ||
| Befestigungsart | With through-hole With H-rail Either: | ||
| Characteristic for inputs | IEC1131-T2 | ||
| Schutzart | IP65 IP67 | ||
| LABS-Konformität | VDMA24364-B2-L | ||
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions | ||
| KC-Zeichen | KC-EMV | ||
| Switching level | Signal 0: <= 6 V Signal 1: >= 8.6 V | ||
| Isolation channel - channel | no | ||
| Max. number of inputs | 16 | ||
| Input debounce time | 3 ms (0.5 ms, 10 ms, 20 ms, parameterisable) | ||
| Operating voltage DC load voltage | 24 V | ||
| LED display | 16 Channel status 2 Module diagnostics 4 Group diagnostics |
