| Cylinder Action | Double Acting | ||
| Bore Diameter | 160mm | ||
| Extend Stroke Force | 12000 N, - | ||
| Cushioning Type | - | ||
| Rod End Thread Type | Male | ||
| Position Sensing Type | - | ||
| Specifications Met | - | ||
| Body Material | Zinc Plated Steel | ||
| Body Type | Square | ||
| Repairable | Yes |
| Cylinder Type | 12000 N / Stroke 50 | ||
| Maximum Stroke Length | 50 mm, 1.9 inch | ||
| Retract Stroke Force | 12000 N, - | ||
| Anschlussgröße | G1/2 | ||
| Maximum Operating Pressure | 8 bar, 116 psi | ||
| Mounting Option | Direct | Piston Rod | ||
| Piston Rod Material | Steel | ||
| End Cap Material | Zinc Plated Steel | ||
| Corrosion Resistance Included | No |
