NORGREN C02250818 pneufit c push-in fitting

Name: C02250818 NORGREN
Brand: NORGREN
SKU: 779530-de-eur
Price: 2.28 EUR
Availability: InStock

2,28 € ~~3,07 €~~ -25%

50+ Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

max. Druck	0 ... 10 bar
Dichtung	nbr (silicone free)

Außendurchmesser	17 mm
Gewicht	25g

body		plastic pbt
data performance shelf life		10 years
male metric bspp		g1/8
metric bspp		g1/8
od tube length millimetre		8 mm
operating pressure psi pressure psi min to max range		0 ... 145 psi
operating temperature temperature celsius min to max range		-20 ... 60 °c
length length millimetre		26.5 mm
Anschlussgröße		g1/8
release sleeve and backing ring		pom
Baureihe		pneufit c
thread		g1/8
thread sealant		threebond 2350b

collar		nickel plated brass
grabring		stainless steel
Medium		compressed air
mil spec		unavailable
operating pressure pressure bar min to max range		0 ... 10 bar
operating temperature f temperature fahrenheit min to max range		-4 ... 140 °f
diameter length millimetre		17 mm
weight weight kilogram		0.03 kg
product style		pif
Dichtungen		nbr (silicone free)
shape		straight
thread form		iso g
threaded bodies		nickel plated brass
