| Valve Type | US Style Gas Valve (ISO 4570-8VI) | ||
| Gas Volume | 0.75 L, 45 cu. in inch3 | ||
| Compression Ratio | 8:01 | ||
| Port Type | SAE #8 (3/4-16 UNF) Female | ||
| Diaphragm Material | Hydrin | ||
| Höhe | 169 mm, 6.65 in inch | ||
| Specifications Met | Consult Factory |
| Nominal Volume (l) | 0.75 l | ||
| Maximum Operating Pressure | 250 bar, 3625 psi | ||
| Maximum Flow Rate | 100 L/min, 26 Gal/min | ||
| Body Material | High Strength Alloy Steel | ||
| Gewicht | 3.0 kg, 6.6 lbs lb | ||
| Diameter | 124 mm, 4.87 in inch | ||
| Repairable | Non-Repairable |
