| Part # | 8M4K-MTFxRL67 | ||
| Continuous Operating Temperature Range | -40°F to +212°F | ||
| Minimum Bend Radius (mm) | 71 | ||
| Hose Inside Diameter (in) | 0,50 | ||
| Inside Diameter (in) | 1/2 | ||
| Temperature Range | -40/100 | ||
| Outside Diameter (mm) | 20,80 | ||
| Verwendung | Wire Braid | ||
| Reinforcement | Two braids of high-tensile steel wire. | ||
| Construction: Reinforcement | 2WB | ||
| Standard Industry Specification | ISO 11237 R19, ISO 18752, SAE 100R19 | ||
| Packaging | F |
| Product # | 4657-01480 | ||
| Minimum Bend Radius (in) | 2,80 | ||
| Min. Burst Pressure (psi) | 16.000 | ||
| Hose Outside Diameter (in) | 0,82 | ||
| Inside Diameter (mm) | 12 | ||
| Outside Diameter (in) | 0,82 | ||
| Specifications | Minimum Burst Pressure (Bar): 1120 | ||
| Cover | UHMWPE | ||
| Tube | Black, oil-resistant, synthetic rubber (Nitrile - Type C). See Hose Stock Characteristics. | ||
| Construction: Tube | NBR | ||
| Weight (lbs.) | 0,44 | ||
| UPC | 072053435573 |
