| Typ | round plug connectors | ||
| Shielding | unshielded | ||
| max. ambient temperature | 90 °c | ||
| Schutzklasse | ip67 | ||
| electrical connection 1, type | socket | ||
| electrical connection 1, number of poles | 4-pin | ||
| cable exit | angled | ||
| Gewicht | 0.027 kg | ||
| seal material | fluorocarbon caoutchouc |
| Anschlussart | screws | ||
| min. ambient temperature | -25 °c | ||
| max. current | 4 a | ||
| operational↩voltage | 48 v ac/dc | ||
| electrical connection 1, thread size | m12x1 | ||
| electrical connection 1, coding | a-coded | ||
| cable exit angle | 90° | ||
| Gehäusematerial | polybutyleneterephthalate |
