| cushioning energy | 88 j | ||
| Kolbenstangengewinde | m20x1,5 | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 80 °c | ||
| extracting piston force | 4635 n | ||
| pressure for determining piston forces | 6,3 bar | ||
| piston rod | through | ||
| magnetic piston | piston with magnet | ||
| Funktionsprinzip | double-acting | ||
| piston Ø | 100 mm | ||
| min. medium temperature | -20 °c | ||
| stroke max. | 1500 mm | ||
| weight 0 mm stroke | 3.7 kg |
| Dämpfungslänge | 495.3 mm | ||
| Anschlüsse | g 1/2 | ||
| working pressure min. | 1.5 bar | ||
| min. ambient temperature | -20 °c | ||
| retracting piston force | 4635 n | ||
| scraper | standard industrial scraper | ||
| environmental requirements | industry standard, atex optional | ||
| Dämpfung | pneumatic adjustable cushioning | ||
| Hub | 100 mm | ||
| Standards | iso 15552 | ||
| Medium | compressed air | ||
| weight +10 mm stroke | 0.104 kg |
