| min. medium temperature | 0 °c | ||
| min. ambient temperature | 0 °c | ||
| control pressure min. | 1.5 bar | ||
| Anschlussart | pipe connection | ||
| pilot valve width | 15 mm | ||
| Dichtprinzip | soft seal | ||
| electrical connection size | iso 15217, form c | ||
| Handhilfsbetätigung | without detent | ||
| voltage tolerance ac 50 hz | -10% / +10% | ||
| operational voltage ac at 50 hz | 110 v | ||
| working pressure min. | 1.5 bar | ||
| switching principle | 5/2 | ||
| activation | electrically |
| max. ambient temperature | 50 °c | ||
| control pressure max. | 10 bar | ||
| return | with spring/air spring return | ||
| valve type | spool valve, positive overlapping | ||
| pilot | internal | ||
| actuating control | double solenoid | ||
| electrical connection type | plug | ||
| voltage tolerance ac 60 hz | -10% / +10% | ||
| operational voltage ac at 60 hz | 110 v | ||
| working pressure max | 10 bar | ||
| compressed air connection output | g 1/8 | ||
| nominal flow qn | 500 l/min |
