| activation | pneumatically | ||
| working pressure min. | 2 bar | ||
| min. ambient temperature | 0 °c | ||
| min. medium temperature | 0 °c | ||
| Medium | compressed air | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| max. suction capacity | 240 l/min | ||
| max. vacuum level at p.opt | 90 % | ||
| Gehäusematerial | aluminum | ||
| nozzle material | brass |
| nozzle Ø | 3 mm | ||
| working pressure max | 6 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 60 °c | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| max. particle size | 5 µm | ||
| air consumption at p.opt. | 420 l/min | ||
| Gewicht | 0.24 kg | ||
| seal material | acrylonitrile butadiene rubber |
