| Bore diameter | d | 110 | mm |
| Breite | B | 38 | mm |
| Shoulder diameter inner ring (small side face) | d2 | ≈127.12 | |
| Distance pressure point | a | 84 | mm |
| Chamfer dimension outer ring small side face | r3,4 | min.1.1 |
| Außen-Ø | d2 | 200 | mm |
| Shoulder diameter inner ring (large side face) | d1 | ≈144.85 | |
| Shoulder diameter outer ring (large side face) | D1 | ≈167.35 | |
| chamfer dimension | rmin | min.2.1 |
| Hersteller | Teilenummer |
|---|---|
| FAG | 7222-B-XL-MP-UA (FAG) |
