| Bore diameter | d | 100 | mm |
| Breite | B | 34 | mm |
| Basic static load rating, radial | C0r | 124,000 | |
| Limiting speed | nG | 6,300 |
| Außen-Ø | D | 180 | mm |
| Basic dynamic load rating, radial | Cr | 142,000 | |
| Fatigue load limit, radial | Cur | 7,300 | |
| Reference speed | nϑr | 4,250 |
| Minimum diameter of shaft shoulder | da min | 112 | mm |
| Maximum diameter of housing shoulder | Db max | 173 | mm |
| Maximum fillet radius of housing | ra1 max | 1 | mm |
| Maximum diameter of housing shoulder | Da max | 168 | mm |
| Maximum fillet radius of shaft | ra max | 2,10 | mm |
| Minimum chamfer dimension | rmin | 1,10 | mm |
| Shoulder diameter on inner ring wide side face | d1 | 132,32 | mm |
| Contact angle | α | 40 | ° |
| Shoulder diameter on outer ring wide side face | D1 | 149,60 | mm |
| Distance between the apexes of the pressure cones | a | 76 | mm |
