| Dämpfung | Short elastic cushioning rings/pads at both ends No cushioning Elastic cushioning rings/plates at both ends Elastic cushioning rings/pads at both ends with fixed stop Self-adjusting, progressive shock absorber at both ends, with reducing sleeve Progressive shock absorber at both ends | ||
| Führung | Ball bearing cage guide | ||
| Positionserkennung | Via proximity switch | ||
| Max. Geschwindigkeit | 0,8 m/s | ||
| Betriebsmedium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Korrosionsbeständigkeitsklasse KBK | 0 - No corrosion stress | ||
| Theoretische Kraft bei 0,6 MPa (6 bar, 87 psi), Rücklauf | 104 N | ||
| Alternativanschlüsse | See product drawing | ||
| Hub | 10 mm ... 150 mm | ||
| Kolben-Ø | 16 mm | ||
| Werkstoff Deckel | Wrought aluminium alloy | ||
| Werkstoff Gehäuse | Wrought aluminium alloy | ||
| Betriebsart der Antriebseinheit | Yoke |
| Einbaulage | optional | ||
| Konstruktiver Aufbau | Yoke Piston Piston rod Slide | ||
| Betriebsdruck | 1 bar ... 8 bar | ||
| Funktionsweise | Double-acting | ||
| Hinweis zum Betriebs-/Steuermedium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Umgebungstemperatur | 0 °C ... 60 °C | ||
| Theoretische Kraft bei 0,6 MPa (6 bar, 87 psi), Vorlauf | 121 N | ||
| Befestigungsart | With through-hole | ||
| Pneumatischer Anschluss | M5 | ||
| Werkstoff-Hinweis | RoHS-compliant | ||
| Werkstoff Dichtungen | HNBR | ||
| Werkstoff Kolbenstange | High-alloy stainless steel |
