| rated power ac | 9 v·a | ||
| reduced power dc | 9 w | ||
| thermal insulation class of the actuator | h | ||
| coil wiring rectifier | yes | ||
| coil size | 49 mm | ||
| coil type | block bolted | ||
| protection type ip (max. with suitable connector) | ip65 | ||
| cable plug in delivery | enclosed | ||
| vacuum version | yes | ||
| switch time close max. | 60 ms | ||
| switch time open max. | 20 ms | ||
| switch function | on/off | ||
| main valve operating principle | globe valve | ||
| operation | direct-acting | ||
| Typ | 131 | ||
| main valve orifice 1 (p) (mm) | 10 mm | ||
| kv value (water) | 2 m3/h | ||
| sealing toward outside material | fkm (fluor rubber) | ||
| seat seal material category | elastomer | ||
| temperature environment min | -10 °c | ||
| temperature medium min | -10 °c | ||
| nominal pressure min | 0 bar | ||
| battery voltage | yes | ||
| ac voltage | yes | ||
| voltage tolerance positive | 10 % | ||
| voltage max / rated voltage | 24 v | ||
| port connection 3 size dn | dn 10 | ||
| port connection 3 type | true union | ||
| port connection 2 size dn | dn 10 | ||
| port connection 1 size dn | dn 10 | ||
| port connection 1 type | bonded sleeve | ||
| manual actuation material | pa (polyamide) | ||
| manual actuation | yes | ||
| fluidic port connection number | 3 |
| inrush power consumption ac | 100 v·a | ||
| rated power dc | 100 w | ||
| coil wiring polarity recovery diode | yes | ||
| coil wiring overvoltage protection | suppressor diode | ||
| coil insulation material (encasement) | epoxy | ||
| kick and drop coil | energy saving technology included | ||
| cable plug art. no. - type | 00314802 - 2518 | ||
| electrical connection number of contacts | 2 + grounding conductor | ||
| nominal operation/duty cycle | 100 % | ||
| switch time close min | 40 ms | ||
| switch time open min | 10 ms | ||
| valve construction | valve complete | ||
| media separation | yes | ||
| actuator type | plunger valve | ||
| main valve orifice 1 (inch) | 3/8 inch | ||
| qnn value (gas) | 2.100 l/min | ||
| rated power consumption | 100 w | ||
| seat seal material | fkm (fluor rubber) | ||
| temperature environment max | 50 °c | ||
| temperature medium max | 50 °c | ||
| nominal pressure max (liquid) | 1 bar | ||
| main valve wetted material | pvc (polyvinyl chloride) | ||
| dc voltage | yes | ||
| voltage tolerance negative | 10 % | ||
| voltage frequency | 50/60 hz | ||
| voltage min / rated voltage | 24 v | ||
| port connection 3 inner diameter (mm) | 16 mm | ||
| port connection 2 inner diameter (mm) | 16 mm | ||
| port connection 2 type | bonded sleeve | ||
| port connection 1 inner diameter (mm) | 16 mm | ||
| manual actuation stop | yes | ||
| manual actuation type | key button | ||
| valve function number of switching positions | 2 | ||
| Customscode | 84818079 |
