| activation | electrically | ||
| working pressure min. | 3 bar | ||
| dc operating voltage | 24 v | ||
| Handhilfsbetätigung | without | ||
| valve type | spool valve | ||
| flow conductance c | 11.3 l/(s*bar) | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| max. particle size | 5 µm | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| Einschaltdauer | 100 % | ||
| Gewicht | 0.39 kg | ||
| seal material | acrylonitrile butadiene rubber |
| nominal flow qn | 3300 l/min | ||
| working pressure max | 10 bar | ||
| voltage tolerance dc | -10% / +10% | ||
| pilot valve width | 30 mm | ||
| power consumption dc | 6.7 w | ||
| min. ambient temperature | -15 °c | ||
| min. medium temperature | -15 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| protection class with connection | ip65 | ||
| typ. switch-off time | 60 ms | ||
| Gehäusematerial | aluminum |
