| Typ | poppet valve | ||
| Standard | iso 15407-1 | ||
| compressed air connection, exhaust | base plate din iso 15407-1 | ||
| working pressure min. | 2 bar | ||
| regulation range min. | 3 bar | ||
| min. ambient temperature | -15 °c | ||
| min. medium temperature | -15 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| qn 1▶2 | 750 l/min | ||
| Gehäusematerial | polyamide fiber-glass reinforced, polyoxymethylene |
| certificates | free of substances that impair surface wetting in the coating process | ||
| controlled port | 3 | ||
| compressed air connection gauge port | Ø 6x1 | ||
| working pressure max | 10 bar | ||
| regulation range max. | 3 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| max. particle size | 50 µm | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| Gewicht | 0.2 kg | ||
| seal material | acrylonitrile butadiene rubber |
