| activation | electrically | ||
| working pressure max | 10 bar | ||
| voltage tolerance dc | -10% / +10% | ||
| pilot valve width | 30 mm | ||
| power consumption | low power consumption | ||
| max. ambient temperature | 50 °c | ||
| protection class with connection | ip65 | ||
| Gewicht | 0.17 kg |
| working pressure min. | 0 bar | ||
| dc operating voltage | 220 v | ||
| Standards | cnomo / nfe 49-003-1 | ||
| power consumption dc | 2 w | ||
| min. ambient temperature | -10 °c | ||
| Medium | compressed air | ||
| Einschaltdauer | 100 % |
