| Brand | NTN | ||
| T - Total width | 36,512 mm | ||
| C - Dynamic load | 158 kN | ||
| Cu - Fatigue limit load | 21,7 kN | ||
| e - Coefficient | 0,40 | ||
| Y2 - Upper axial load coefficient | 1,49 | ||
| Nlim - Grease lubrication limit speed | 3700 tr/min | ||
| Tmax - Max operating temperature | 120 °C | ||
| BPFI - Characteristic inner ring frequency | 9,313 Hz | ||
| BSF - Characteristic rolling element frequency | 5,727 Hz | ||
| db min - Min IR shoulder diameter | 68 mm | ||
| Db min - Min OR shoulder diameter | 99 mm | ||
| r1a - Max fillet radius | 3,3 mm |
| C - Outer ring width | 28,575 mm | ||
| a - Charge load application point | 26,912 mm | ||
| C0 - Static load | 178 kN | ||
| A2 - Rating life coefficient | 1 | ||
| Y0 - Static axial load coefficient | 0,82 | ||
| Nlim - Oil lubrication limit speed | 4900 tr/min | ||
| Tmin - Min operating temperature | -40 °C | ||
| BPFO - Characteristic outer ring frequency | 6,687 Hz | ||
| FTF - Characteristic cage frequency | 0,418 Hz | ||
| da max - Max shoulder diameter IR | 61 mm | ||
| Da max - Max shoulder diameter OR | 92 mm | ||
| ra max - Max fillet radius | 3,5 mm |
