| r1a - Max fillet radius | 3,3 mm | ||
| Db min - Min OR shoulder diameter | 63 mm | ||
| db min - Min IR shoulder diameter | 44,5 mm | ||
| BSF - Characteristic rolling element frequency | 6,817 Hz | ||
| BPFI - Characteristic inner ring frequency | 10,255 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Grease lubrication limit speed | 5600 tr/min | ||
| Y2 - Upper axial load coefficient | 1,57 | ||
| e - Coefficient | 0,38 | ||
| C0 - Static load | 58 kN | ||
| r1s - Min fillet radius | 3,3 mm | ||
| a - Charge load application point | 15,7 mm | ||
| C - Outer ring width | 15,875 mm |
| ra max - Max fillet radius | 3,5 mm | ||
| Da max - Max shoulder diameter OR | 59 mm | ||
| da max - Max shoulder diameter IR | 38,5 mm | ||
| FTF - Characteristic cage frequency | 0,43 Hz | ||
| BPFO - Characteristic outer ring frequency | 7,745 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nlim - Oil lubrication limit speed | 7400 tr/min | ||
| Y0 - Static axial load coefficient | 0,86 | ||
| A2 - Rating life coefficient | 1 | ||
| C - Dynamic load | 53,5 kN | ||
| rs - Min fillet radius | 3,5 mm | ||
| T - Total width | 19,845 mm | ||
| Brand | NTN |
