462-8 Parker Hannifin

PARKER 462-8

Name: 462-8 PARKER
Brand: PARKER
SKU: 576799-de-eur
Price: 28.27 EUR
Availability: InStock

28,27 € /m ~~56,54 €~~ /m -50%

50 m mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Parker Elite No-Skive Compact Hose 462 has been designed for a working pressure up to 42,5 MPa and a temp. range from -40 °C up to +100 °C. The hose range is compatible with No-Skive fittings in steel and stainless steel

max. Druck	31.0 mpa, 4495 psi, 310 bar

Gewicht	520g

Technical data

minimum bend radius		80 mm
hose i.d. (size)		-8
Brand		parker
industry		general industrial, off-road machinery
technology		fluid & gas handling
product style		elite no-skive compact
hose inside diameter		12.7 mm, 1/2 inch
design factor		4:1
compatible fitting		46 series, 48 series
Minimale Betriebstemperatur		-40 °c
materials of construction		rubber
hose inner tube material		nitrile nbr
Gewicht		0.52 kg/m, 0.35 lb/ft

hose cover type		standard
media		fuels (check fuel type with our catalogue chart)., coolants i.e. glycol, industrial air, lubricants, mineral hydraulic oil, water
division		polymer hose division europe
Anwendung		demanding medium pressure hydraulic applications in all markets
Produktfamilie		hydraulic hose, specialty hose
maximum operating pressure		31.0 mpa, 4495 psi, 310 bar
hose outside diameter		20.4 mm, 0.803 inch
cover color		black
Maximale Betriebstemperatur		100 (water: 85, air: 70) °c, 212 (water: 185, air: 158) °f
specifications met		en 857 - 2sc - iso 11237 type 2sc, en 857 2sc, iso 11237 type 2sc
cover material		synthetic rubber
hose reinforcement material		two high-tensile steel wire braids
