| hose cover type | standard | ||
| media | hydraulic fluids, petroleum & water-glycol based fluids, lubricating oils, air & water, fuels (check fuel type with our catalogue chart)., coolants i.e. glycol, industrial air, lubricants, water, mineral hydraulic oil | ||
| Brand | parker | ||
| industry | industrial manufacturing equipment, off-road machinery, transportation | ||
| technology | fluid & gas handling | ||
| product style | no-skive | ||
| hose inside diameter | 3/4 inch, 19.1 mm | ||
| minimum bend radius | 240 mm, 9.449 inch | ||
| cover color | black | ||
| Maximale Betriebstemperatur | 100 °c (water: 85 , air: 70), 212 °f (water: 185, air: 158) | ||
| materials of construction | rubber | ||
| hose inner tube material | nitrile nbr | ||
| Gewicht | 0.63 kg/m, 0.42 lb/ft |
| hose i.d. (size) | -12 | ||
| Minimale Betriebstemperatur | -40 °f, -40 °c | ||
| division | polymer hose division europe | ||
| Anwendung | general medium pressure hydraulic applications | ||
| Produktfamilie | hydraulic hose, specialty hose | ||
| maximum operating pressure | 10.5 mpa, 1525 psi, 105 bar | ||
| hose outside diameter | 27.8 mm, 1.094 inch | ||
| design factor | 4:1 | ||
| compatible fitting | 48 series | ||
| specifications met | en 853 1sn, iso 1436 type 1, sae 100r1at, en 853 1sn - iso 1436 type 1 - sae 100r1at | ||
| cover material | synthetic rubber | ||
| hose reinforcement material | 1 high-tensile steel wire braid |
