| Body Material | Aluminium | ||
| Charge Pump Included | No | ||
| Configuration | Single | ||
| Energy Recovery Capability | NO | ||
| For Fluid Type | Standard Hydraulic Fluid | ||
| Maximum Flow Rate | 190 L/min, 50.16 Gal/min | ||
| Maximum Operating Pressure | 350 bar, 5075 psi | ||
| Maximum Operating Speed | 2300 RPM | ||
| Minimum Kinematic Viscosity | 47 SUS | ||
| Media | Hydraulic | ||
| Leitungsanschlüsse | SAE | ISO | BSPP | ||
| Port Location | REAR PORTS | ||
| Drehrichtung | CLOCKWISE | COUNTER CLOCKWISE | ||
| Shaft Type | SAE | ISO | DIN |
| Drain Option | NO | ||
| Circuit Path | OPEN | ||
| Control Method | Consult Parker | ||
| Filter Included | NO | ||
| Maximum Displacement | 121 cm3/rev, 7.38 inch3/rev | ||
| Maximum Noise Level | Consult Parker dBA | ||
| Radial Load Capacity | Consult Parker kg, Consult Parker lb | ||
| Maximum Kinematic Viscosity | 1866 SUS | ||
| Gewicht | 12.5 kg (Max), 27.5 lb (Max) | ||
| Mounting Option | SAE | ISO | DIN | ||
| Port Type | Consult Parker | ||
| Pump Type | Fixed, Piston | ||
| Sensorart | Consult Parker | ||
| Thru-Drive Capability | NO |
