| Typ | ball valve | ||
| Medium | compressed air | ||
| compressed air connection type 1 | internal thread | ||
| compressed air connection type 2 | internal thread | ||
| max. ambient temperature | 150 °c | ||
| max. medium temperature | 150 °c | ||
| working pressure max | 40 bar | ||
| Gehäusematerial | brass | ||
| Material hand lever | steel, chrome-plated |
| switching principle | 2/2 | ||
| compressed air connection 1 | g 3/4 | ||
| compressed air connection 2 | g 3/4 | ||
| min. ambient temperature | -20 °c | ||
| min. medium temperature | -20 °c | ||
| working pressure min. | -0.8 bar | ||
| Gewicht | 0.34 kg | ||
| seal material | polytetrafluorethylene |
