| Body Material: | Aluminium | ||
| Configuration: | Single | ||
| Filter Efficiency Rating: | According to ISO 4406 Cl. 19/17/13 | ||
| Maximum Operating Pressure: | 250 bar | ||
| Mounting Type: | SAE A 2-Bolt | Rectangular | Thrubolt Flange | 4 Bolt Flange | ||
| Port Location: | Side Ports | Rear Ports | ||
| Pump Type: | Fixed, Gear | ||
| Shaft Type: | SAE A Splined | Taper Key | DIN ISO 14 |
| Circuit Path: | Open | ||
| Control Method: | Consult Parker | ||
| For Fluid Type: | Standard Hydraulic Fluid / Phosphate Ester / Water Glycol / Biodegradable | ||
| Weight: | 4.5 kg (Max) | ||
| Port Type: | BSP Thread | Square | Diamond | ||
| Displacement: | Pump: 6 to 33 cm3/rev | ||
| Direction of Rotation: | Clockwise | Counter Clockwise | ||
| Operating Speed: | 500 to 3500 RPM |
