| connection 1 thread size (metric) | m5x0, 8 | ||
| connection 1 thread style | metric | ||
| Produktfamilie | stud fittings | ||
| o-ring material | nbr | ||
| Minimale Betriebstemperatur | -15 °c | ||
| quantity per box | 10 | ||
| Anwendung | pneumatic panels, robotics, semi-conductors, textile, pneumatics, vacuum | ||
| specifications met | iso 14743 iso 14743, di: 97/23/ec (ped), di: 2002/95/ec (rohs), 2011/65/ec, di: 94/9/ec (atex ), rg: 1907/2006 (reach) |
| connection 2 tube o.d. (mm) | 3 | ||
| body material | nickel plated brass | ||
| shape | male stud fitting thread | ||
| maximum operating pressure | 18 barg | ||
| Maximale Betriebstemperatur | 70 °c | ||
| Gewicht | 0,002 kg | ||
| media | compressed air |
