| r1a - Max fillet radius | 1,5 mm | ||
| Cb - Min clearance | 5,5 mm | ||
| Db min - Min OR shoulder diameter | 97 mm | ||
| Da min - Min shoulder diameter OR | 90 mm | ||
| da max - Max shoulder diameter IR | 72 mm | ||
| FTF - Characteristic cage frequency | 0,45 Hz | ||
| BPFO - Characteristic outer ring frequency | 12,161 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nref - Reference thermal speed | 4100 tr/min | ||
| Y0 - Static axial load coefficient | 0,72 | ||
| Cu - Fatigue limit load | 21,6 kN | ||
| A2 - Rating life coefficient | 1 | ||
| ISO 355 reference | T4CC065 | ||
| rs - Min fillet radius | 1,5 mm | ||
| T - Total width | 23 mm | ||
| Brand | SNR |
| ra max - Max fillet radius | 1,5 mm | ||
| Ca - Min clearance | 4 mm | ||
| Da max - Max shoulder diameter OR | 91,5 mm | ||
| db min - Min IR shoulder diameter | 73,5 mm | ||
| BSF - Characteristic rolling element frequency | 9,549 Hz | ||
| BPFI - Characteristic inner ring frequency | 14,839 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Mechanical Limit Speed | 6800 tr/min | ||
| Y2 - Upper axial load coefficient | 1,31 | ||
| e - Coefficient | 0,46 | ||
| C0 - Static load | 132 kN | ||
| C - Dynamic load | 87,5 kN | ||
| r1s - Min fillet radius | 1,5 mm | ||
| a - Charge load application point | 22,3 mm | ||
| C - Outer ring width | 17,5 mm |
