| operating pressure - max | 6000 psi (420 bar) | ||
| Dichtungsmaterial | nitrile | ||
| Material | stainless steel | ||
| operating temperature - max | 80 °c | ||
| indicator type | electrical/visual | ||
| filter type | clogging indicator | ||
| Produktgewicht | .23 kg | ||
| product height | 93 mm |
| Anwendung | wide range of clogging indicators for hydraulic and lubrication systems | ||
| specification | va - stainless steel | ||
| Anschlussart | g 1/2" threaded | ||
| operating temperature - min | -10 °c | ||
| code stamp | none | ||
| compliances | din en 61140 class 2 | ||
| product width | 30 mm | ||
| product length/depth | 76.5 mm |
