| Bore diameter | d | 25 | mm |
| Total bearing width | T | 16,25 | mm |
| Width Inner ring | B | 15 | mm |
| Corner radius inner ring | r1,2 | min.1 | |
| Distance pressure point | a | 12,33 | mm |
| Außen-Ø | d2 | 52 | mm |
| Inner ring shoulder diameter | d1 | ≈38 | |
| Width Outer ring | C | 13 | mm |
| Corner radius outer ring | r3,4 | min.1 |
