| rated insulation voltage (ui) | 440 v | ||
| rated operational voltage (ue) - max | 230 v | ||
| connectable conductor cross section (multi-wired) - max | 16 mm² | ||
| connectable conductor cross section (solid-core) - min | 1.5 mm² | ||
| built-in depth | 60 mm | ||
| connectable conductor cross section (multi-wired) - min | 2 mm² | ||
| ambient operating temperature - max | 55 °c | ||
| Overvoltage category | iii | ||
| number of poles (total) | 4 | ||
| rated short-circuit breaking capacity (iec 60947-2) at 400 v | 15 ka | ||
| frequency rating - max | 60 hz | ||
| rated short-circuit breaking capacity (en 60898) at 400 v | 10 ka | ||
| release characteristic | other | ||
| rated short-circuit breaking capacity (en 60898) at 230 v | 10 ka | ||
| compliances | rohs conform | ||
| product width | 70.8 mm | ||
| product length/depth | 72.6 mm |
| voltage type | ac | ||
| frequency rating - min | 50 hz | ||
| ambient operating temperature - min | -20 °c | ||
| Features | additional equipment possible | ||
| rated impulse withstand voltage (uimp) | 4 kv | ||
| Verschmutzungsgrad | 2 | ||
| rated short-circuit breaking capacity (iec 60947-2) at 230 v | 15 ka | ||
| Schutzart | ip20 | ||
| connectable conductor cross section (solid-core) - max | 35 mm² | ||
| width in number of modular spacings | 4 | ||
| amperage rating | 63 a | ||
| current limiting class | 3 | ||
| suitable for | flush-mounted installation | ||
| number of poles (protected) | 4 | ||
| Produktgewicht | .492 kg | ||
| product height | 80 mm | ||
| ean | 9010238117976 |
