| Minimum chamfer dimension | rmin | 3 | mm |
| Diameter lubrication hole | ds | 4,80 | mm |
| Bore diameter outer ring | D1 | 199,30 | mm |
| Width of lubricating groove | ns | 9,50 | mm |
| Bore diameter | d | 130 | mm |
| Breite | B | 80 | mm |
| Basic static load rating, radial | C0r | 1,150,000 | |
| Limiting speed | nG | 2,850 |
| Außen-Ø | D | 230 | mm |
| Basic dynamic load rating, radial | Cr | 910,000 | |
| Fatigue load limit, radial | Cur | 91,000 | |
| Reference speed | nϑr | 1,740 |
| Minimum diameter shaft shoulder | da min | 144 | mm |
| Maximum recess radius | ra max | 2,50 | mm |
| Maximum diameter of housing shoulder | Da max | 216 | mm |
