| Bore diameter | d | 170 | mm |
| Breite | B | 88 | mm |
| Shoulder/recess diameter of outer ring | D1 | ≈244 | |
| diameter of lubrication hole | S | 7,50 | mm |
| Außen-Ø | d2 | 280 | mm |
| Shoulder diameter of inner ring | d2 | ≈195 | |
| Width of lubrication groove | b | 13,90 | mm |
| chamfer dimension | rmin | min.2.1 |
