| product series | cls181 : load sense sectional mobile valves | ||
| actuation type | e : electrohydraulic with lever override | ||
| spool type | d : double acting (4 way) cylinder | ||
| port a spool flow | 180 : 180 lpm | ||
| coil type | c : 12v coil deutsch connector | ||
| port a option setting | 000 : none | ||
| port b option setting | 000 : none | ||
| ls relief setting | 000 : 000 bar | ||
| lever kits | a : 135mm (5.5”) lever kit | ||
| special features | 00 : no special features |
| compensation type | p : post-compensated | ||
| port type | b : g3/4 bsp (g1/4 pilot if hyd., g1/8 if pneumatic) | ||
| spool action | a : spring centered to neutral | ||
| port b spool flow | 180 : 180 lpm | ||
| port a option function | p : plugged | ||
| port b option function | p : plugged | ||
| local ls relief option | z : no ls relief | ||
| spool stroke limiter or position indicator | a : electrohydraulic section w/spool stroke limiter | ||
| build type | r : right hand | ||
| design level | b : latest design |
