AVENTICS 2122106180

Name: 2122106180 AVENTICS
Brand: AVENTICS
SKU: 751270-de-eur
Price: 6.29 EUR
Availability: InStock

QR1-S-RVL-G018-DA06

6,29 € ~~7,52 €~~ -16%

31 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

max. Druck	16 bar
Dichtung	acrylonitrile butadiene rubber

Gewicht	31g

fitting type		long elbow fitting
Anschluss G		g 1/8
port d		Ø 6
working pressure min.		-1 bar
min. ambient temperature		-20 °c
min. medium temperature		-20 °c
delivery unit		10 piece
Gehäusematerial		polyamide
material tooth lock washer		stainless steel
material release ring holder		die cast zinc

compressed air connection type		external thread
compressed air connection type 2		push-in fitting
Typ		qr1-s-rvl
working pressure max		16 bar
max. ambient temperature		80 °c
max. medium temperature		80 °c
Gewicht		0.0306 kg
seal material		acrylonitrile butadiene rubber
Werkstoff Lösering		polyamide
material thread		brass
