PARKER 2030T-16V70

Name: 2030T-16V70 PARKER
Brand: PARKER
SKU: 749778-de-eur
Price: 88.04 EUR
Availability: InStock

88,04 € /m ~~176,08 €~~ /m -50%

verfügbar mit 3 bis 4 Wochen Lieferzeit nach United States

Technische Daten

max. Druck	1160 psi, 8 mpa, 80 bar

Gewicht	510g

hose i.d. (mm)		25
maximum working pressure (mpa)		8
Baugröße		-16
division		polymer hose division europe
Anwendung		high temperatures and/or aggresive media
Produktfamilie		hydraulic hose, ptfe hose, transfer hose
maximum operating pressure		1160 psi, 8 mpa, 80 bar
hose outside diameter		29 mm, 1.142 inch
design factor		4:1
Maximale Betriebstemperatur		230 °c, 446 °f
specifications met		parker specifications
hose inner tube material		polytetrafluoroethylene
Gewicht		0.51 kg/m, 0.34 lb/ft

weight (kg/m)		0,51
media		aggressive chemicals fluids, hydraulic fluids, aggressive chemicals (check your fluid compatibility with our catalogue chart)., mineral hydraulic oil
Brand		parker
industry		general industrial
technology		fluid & gas handling
product style		ptfe hose
hose inside diameter		1 inch, 25 mm
minimum bend radius		250 mm, 9.843 inch
compatible fitting		yx series
Minimale Betriebstemperatur		-58 °f, -50 °c
materials of construction		thermoplastic
hose reinforcement material		1 braided layer of stainless steel
