| Werkstoff Anschlussplatte | Die-cast aluminium | ||
| Pneumatischer Anschluss 5 | G1 | ||
| Pneumatischer Anschluss 3 | G1 | ||
| Pneumatischer Anschluss 1 | G1 | ||
| Umgebungstemperatur | -10 °C ... 60 °C | ||
| Mediumstemperatur | -10 °C ... 60 °C | ||
| Zulassung | UL - Recognized (OL) | ||
| Max. number of valve positions | 1 |
| Werkstoff-Hinweis | RoHS-compliant | ||
| Pneumatischer Anschluss 4 | G1/2 | ||
| Pneumatischer Anschluss 2 | G1/2 | ||
| Mounting method for sub-base | With through-hole | ||
| Schutzart | IP65 | ||
| Betriebsmedium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Betriebsdruck | -0,9 bar ... 16 bar | ||
| Basierend auf Norm | ISO 5599-2 |
