| motors | delta motor/lg black | ||
| Baureihe | dl : delta series | ||
| Mounting type | aa : wheel, 4 bolt, 82.6 [3.25] pilot dia. 13.59[.535] dia. holes on 147.6 [5.81] dia. bolt circle. 127.0 [5.00] dia. rear mount pilot | ||
| Anschlüsse | aa : .875-14 unf-2b sae o-ring ports | ||
| geroler option | 0 : standard | ||
| accessories | 00 : none | ||
| special features (assembly) | 00 : none | ||
| customer identification | 00 : none |
| Produkt | m : motor | ||
| Schluckvolumen | 183 : 300 cm3/r [18.3 in3/r] | ||
| output shaft | 02 : 31.75 [1.250] dia. .125;1 tapered shaft per sae j501 with 1.000-20 unef-2a threaded shaft end and slotted hex nut, 7.938[.3125] sq x 25.40 [1.000] straight key | ||
| pressure/flow option | 0 : none | ||
| seal option | 0 : standard | ||
| special features (hardware) | 00 : none | ||
| paint/packaging | ab : primer low gloss black, individual box | ||
| design code | b : two(2) |
