| coil width | 22 mm | ||
| connector standard | en 175301-803, form b | ||
| duty cycle ed | 100 % | ||
| Electrical connection 2 | plug | ||
| dc operating voltage | 60 v | ||
| operational voltage ac at 60 hz | 110 v | ||
| voltage tolerance ac 50 hz | -10% / +10% | ||
| holding power ac 50 hz | 8.4 va | ||
| switch-on power ac 50 hz | 11 va | ||
| power consumption dc | 5.9 w | ||
| housing | thermoplastic elastomer |
| max. ambient temperature | 50 °c | ||
| Schutzklasse | ip65 | ||
| compatibility index | 14 | ||
| number of poles | 3-pin | ||
| operational voltage ac at 50 hz | 110 v | ||
| voltage tolerance dc | -10% / +10% | ||
| voltage tolerance ac 60 hz | -10% / +10% | ||
| holding power ac 60 hz | 6.8 va | ||
| switch-on power ac 60 hz | 9.4 va | ||
| Gewicht | 0.07 kg |
