NORGREN 18-015-991 gauges

Name: 18-015-991 NORGREN
Brand: NORGREN
SKU: 782805-de-eur
Price: 21.83 EUR
Availability: InStock

21,83 €

1 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Einbaulage	centre back
max. Druck	0 ... 1.6 bar

Außendurchmesser	40 mm
Gewicht	55g

data performance shelf life		10 years
maximum inlet pressure imperial pressure psi		23 psig
mil spec		unavailable
operating pressure pressure bar min to max range		0 ... 1.6 bar
operating temperature temperature celsius min to max range		-20 ... 65 °c
length length millimetre		60 mm
Anschlussgröße		r1/8
scale bar pressure bar min to max range		0 ... 1.6 bar
scale psi pressure psi min to max range		0 ... 23 psi

eu country of origin		china
maximum inlet pressure pressure bar		1.6 bar
mounting		centre back
operating temperature f temperature fahrenheit min to max range		-4 ... 149 °f
diameter length millimetre		40 mm
port connections		r1/8
range		18-015
scale mpa pressure mpa min to max range		0 ... 0.16 mpa
