| UPC | 051712255097 | ||
| product length/depth | 305 mm | ||
| product width | 145 mm | ||
| warranty | not applicable | ||
| certifications | iec rated ul recognized |
||
| interrupt rating | 100 kaic | ||
| clearing (i2t) | 16000 at 1000 v, 21000 at 1250 v | ||
| center-to-center distance of connections | 108 mm | ||
| insulated metal gripping lugs (imgl) | no | ||
| amperage rating | 160 a | ||
| utilization category | ar (accompanied semiconductor protection) | ||
| fuse type | din 43653 tn/110 type t indicator for micro bolted tag |
||
| fuse shape | square body, slotted center bolted tags | ||
| fuse size | 1* | ||
| pre arc (i2t) | 2.600 | ||
| Anwendung | semiconductor, dc common bus, dc drives, power converters/rectifiers | ||
| packaging type | standard |
| ean | 5027590444897 | ||
| product height | 65 mm | ||
| Produktgewicht | 416.6666667 g | ||
| compliances | ce marked rohs compliant |
||
| fuse indicator | top fuse status indicator | ||
| construction size | other | ||
| rated voltage ac | 1250 v | ||
| Color | none | ||
| current type | ac | ||
| mounting dimension | m10 | ||
| watt losses | 40 w | ||
| Typ | fuse | ||
| breaking capacity | 100 ka | ||
| class | class ar | ||
| voltage rating | 1250 v (iec), 1300 v (ul) | ||
| voltage type | ac |
