EATON 170M2693

Name: 170M2693 EATON
Brand: EATON
SKU: 801865-de-eur
Price: 157.42 EUR
Availability: InStock

157,42 € ~~314,84 €~~ -50%

6 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Breite	85 mm

Gewicht	218g

packaging type		standard
Anwendung		semiconductor, dc common bus, dc drives, power converters/rectifiers
pre arc (i2t)		13
breaking capacity		200 ka
fitted with:		type t indicator for micro
fuse type		din 43620 t indicator for micro bladed
utilization category		gr (general purpose semiconductor protection)
current type		ac
insulated metal gripping lugs (imgl)		no
rated voltage ac		690 v
interrupt rating		200 kaic
certifications		ul recognized iec rated
warranty		not applicable
product width		85 mm
product length/depth		217 mm
UPC		051712264853

voltage type		ac
voltage rating		690 v (iec)
class		class gr
fuse shape		square body, knife blade contacts
Typ		fuse
watt losses		6 w
amperage rating		20 a
Anschluss		blade end x din 43-620 blade end
Color		none
clearing (i2t)		70 at 600 v
fuse indicator		top fuse status indicator
compliances		ce marked rohs compliant
Produktgewicht		217.6666667 g
product height		65 mm
ean		5027590442787
