| max. medium temperature | 75 °c | ||
| Medium | compressed air | ||
| weight +10 mm stroke | 0.1 kg | ||
| Dämpfungslänge | 19.5 mm | ||
| Anschlüsse | g 1/2 | ||
| working pressure min. | 2 bar | ||
| min. ambient temperature | -20 °c | ||
| retracting piston force | 4230 n | ||
| scraper | standard industrial scraper | ||
| environmental requirements | industry standard | ||
| Dämpfung | pneumatic adjustable cushioning | ||
| Hub | 125 mm | ||
| Standards | iso 6431 |
| min. medium temperature | -20 °c | ||
| stroke max. | 1700 mm | ||
| weight 0 mm stroke | 3.7 kg | ||
| Kolbenstangengewinde | m20x1,5 | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 75 °c | ||
| extracting piston force | 4680 n | ||
| pressure for determining piston forces | 8 bar | ||
| piston rod | single | ||
| magnetic piston | piston with magnet | ||
| Funktionsprinzip | double-acting | ||
| piston Ø | 100 mm |
