| Bore diameter | d | 25,40 | mm |
| Total bearing width | T | 19,05 | mm |
| Width Inner ring | B | 20,64 | mm |
| Corner radius inner ring | r1,2 | min.0.8 | |
| Distance pressure point | a | 12,68 | mm |
| Außen-Ø | d2 | 62 | mm |
| Inner ring shoulder diameter | d1 | ≈45.8 | |
| Width Outer ring | C | 14,29 | mm |
| Corner radius outer ring | r3,4 | min.1.3 |
