BURKERT 144074

Name: 144074 BURKERT
Brand: BURKERT
SKU: 843767-de-eur
Price: 254.13 EUR
Availability: InStock

254,13 € (zzgl. MwSt.)

1 Stk. mit 1 bis 3 Tagen Lieferzeit nach Germany

Technische Daten

Dichtung	fkm (fluor rubber)
Gewicht	368g

coil wiring overvoltage protection		without
electrical power consumption min		2,2 w
protection type ip (max. with suitable connector)		ip65
cable plug in delivery		not included
switch time close max.		40 ms
valve piloting type		electric
return type		pneumatic spring + mechanical spring
Typ		6.518
pilot control orifice (mm)		1,2 mm
pilot control seal material		fkm (fluor rubber)
temperature environment max		55 °c
temperature medium max		55 °c
nominal pressure max		10 bar
pilot control material environment-contacting		pa (polyamide)
main valve material environment-contacting		pa (polyamide)
battery voltage		yes
voltage max / rated voltage		24 v
working connection material		brass
working connection thread type		g
working connection diameter (inch)		1/4 inch
supply connection thread type		g
supply connection diameter (inch)		1/4 inch
manual actuation screw slot		no manual actuation available
manual actuation material		no manual actuation available
valve function number of switching positions		2
Customscode		84812090

electircal power consumption max.		2,2 w
coil size		32 mm
electrical connection position		supply side
nominal operation/duty cycle		100 %
switch time open max.		20 ms
main valve operating principle		globe valve
product sub-group		pneumatic valves
main valve orifice 1 (p) (mm)		8 mm
qnn value (gas)		1.300 l/min
main valve seal material		pur (polyurethane)
temperature environment min		-25 °c
temperature medium min		-10 °c
nominal pressure min		2 bar
pilot control material medium-contacting		pa (polyamide)
main valve wetted material		pa (polyamide)
dc voltage		yes
voltage min / rated voltage		24 v
working connection position		opposite of supply side
working connection type		inner thread
flange		fm03
supply connection type		inner thread
add-on dimension 1		33 mm
manual actuation stop		no manual actuation available
manual actuation type		nonexistent
fluidic port connection number		3
