| Brand | SNR | ||
| rs - Min fillet radius | 2 mm | ||
| C - Dynamic load | 41,6 kN | ||
| Cu - Fatigue limit load | 0,65 kN | ||
| Y0 - Static axial load coefficient | 2,73 | ||
| Y2 - Upper axial load coefficient | 4,03 | ||
| Nlim - Mechanical Limit Speed | 8300 tr/min | ||
| Tmax - Max operating temperature | 120 °C | ||
| BPFI - Characteristic inner ring frequency | 8,74 Hz | ||
| BSF - Characteristic rolling element frequency | 5,806 Hz | ||
| Da max - Max shoulder diameter OR | 101 mm |
| D1 - Inner diameter outer ring | 92,7 mm | ||
| Radial clearance class | CN | ||
| C0 - Static load | 14,2 kN | ||
| e - Coefficient | 0,24 | ||
| Y1 - Lower axial load coefficient | 2,60 | ||
| Nref - Reference thermal speed | 6300 tr/min | ||
| Tmin - Min operating temperature | -20 °C | ||
| BPFO - Characteristic outer ring frequency | 6,26 Hz | ||
| FTF - Characteristic cage frequency | 0,417 Hz | ||
| da min - Min shoulder diameter IR | 59 mm | ||
| ra max - Max shaft & housing fillet radius | 2 mm |
