HANSENANDGROMELLE 10FFS37BS

Name: 10FFS37BS HANSENANDGROMELLE
Brand: HANSENANDGROMELLE
SKU: 817881-de-eur
Price: 64.2 EUR
Availability: SoldOut

64,20 €

Begrenzter Lagerbestand nur auf Anfrage erhältlich

Technische Daten

Breite	1.26 inch / 32.00 mm
Dichtung	nbr+au

Gewicht	240g

Betriebsdruck		5075 pound per square inch / 349.91 bar
Drehmoment		31.5 lb/ft / 46.88 kg/m
thread sealant		no
sub brand		hansen and gromelle
safety locking mechanism		sleeve lock
Produktgewicht		.539 pound / 0.24 kg
product trade name		ff series
product material		carbon steel
product height		1.26 inch / 32.00 mm
maximum working temperature		212 fahrenheit / 100 celcius
item type		female half
hex size 1		1.06 inch / 26.92 mm
fluid loss		.006 cubic centimeter
finish/plating		guardian seal
end type 1		bspp
compliances		rohs compliant\|reach
catalog number		10ffs37bs
Brand		danfoss
Anwendung		hydraulic and fluid transfer, construction equipment, agricultural equipment, utility vehicles, on-highway vehicles, stationary in-plant hydraulics and fluid transfer, interchangeable with htma couplings in the 3/8ö size
air inclusion (max)		.01 cubic centimeter
quick disconnect coupling		fem.16028 -10 tar.3/8'g.

valve type		2 way
thread size 1		43.532
taxonomy		quick disconnect couplings
seal material		nbr+au
product width		1.26 inch / 32.00 mm
product volume		4.24 cubic inch / 69,481.30 cubic mm
product name		socket
product length		2.67 inch / 67.82 mm
minimum working temperature		-13 fahrenheit / -25 celcius
marketing description		danfossÆs ff series flat face is specifically designed for those applications where quick and easy connections and no-spill performance are essential. the ff series is ideal for use when global interchangeability with other manufacturers is important and is important and is available in sizes from 1/4 inch through 2 inch to best meet your specific size requirements.
internal connection type		flat face
gtin type		u
flow rate		7.7 gallons per minute / 29.15 liters per minute
feature		push-to-connect\|standard sleeve lock prevents accidental disconnection\|color identification rings available to help prevent crossing of lines\|meets or exceeds iso 16028 standard
connection style		manual connect
certifications		iso 16028
Burst pressure		20300 pound per square inch / 1,399.64 bar
body size		43.898
angle (shape)		straight
*long description		danfoss hansen and gromelle 10ffs37bs ff series socket carbon steel 3/8-19 bspp
