| compressed air connection 1 | g 3/8 | ||
| mounting | installing in piping | ||
| Typ | poppet valve | ||
| compressed air connection 12 | g 1/8 | ||
| nominal flow qn 2 to 1 | 2100 l/min | ||
| working pressure max | 12 bar | ||
| max. ambient temperature | 60 °c | ||
| max. medium temperature | 60 °c | ||
| Gewicht | 0.23 kg | ||
| seal material | acrylonitrile butadiene rubber |
| compressed air connection type 1 | internal thread | ||
| compressed air connection type 2 | internal thread | ||
| compressed air connection 2 | g 3/8 | ||
| nominal flow qn 1 to 2 | 2400 l/min | ||
| working pressure min. | 1 bar | ||
| min. ambient temperature | -10 °c | ||
| min. medium temperature | -10 °c | ||
| Medium | compressed air | ||
| Gehäusematerial | die cast zinc |
