| Bore diameter | d | 6 | mm |
| Outside diameter bearing pot | D | 20,50 | mm |
| Outside diameter bearing pot lower tolerance | -0,01 | mm | |
| Inner ring width upper tolerance | 0,25 | mm | |
| Basic dynamic load rating, radial | Cr | 4,100 | |
| Basic dynamic load rating, axial | Ca | 1,650 | |
| Fatigue load limit, radial | Cur | 107 | N |
| Bore diameter lower tolerance | -0,01 | mm | |
| Outside diameter bearing pot upper tolerance | 0,03 | mm | |
| Width, inner ring | Bi | 12 | mm |
| Inner ring width lower tolerance | -0,25 | mm | |
| Basic static load rating, radial | C0r | 2,060 | |
| Basic static load rating, axial | C0a | 1,520 | |
| Bearing friction torque | MRL | 0,03 | Nm |
| Diameter shaft shoulder | da | 8 | mm |
| Minimum support diameter outer ring outside | Daa min | 19 | mm |
| Number of screws | n | 4 | |
| Number of screws b | n | 2 |
| Support diameter outer ring inside | Dai | 16 | mm |
| Screw size | M4 | ||
| Screw size b | M6 |
| Rib diameter inner ring | d1 | 9 | mm |
| Fixing boring diameter | d2 | 4,50 | mm |
| Height flange | A2 | 35 | mm |
| Bore distance height | m | 26 | mm |
| Distance fixing groove | M | 32 | mm |
| Minimum chamfer dimension | rmin | 0,30 | mm |
| Flange width | A | 24 | mm |
| Wide fixing groove | b | 6,60 | mm |
| bore distance width | n | 15 | mm |
| Height housing | A | 13 | mm |
