| Bore diameter | d | 25 | mm |
| Außen-Ø | D | 75 | mm |
| Breite | B | 28 | mm |
| Basic dynamic load rating, axial | Ca | 27,500 | |
| Fatigue load limit, axial | Cua | 2,500 | |
| Thermally safe operating speed | nϑ | 2,600 |
| Bore diameter lower tolerance | -0,01 | mm | |
| Outside diameter lower tolerance | -0,01 | mm | |
| Width lower tolerance | -0,25 | mm | |
| Basic static load rating, axial | C0a | 55,000 | |
| Limiting speed for grease lubrication | nG Grease | 2,600 | |
| Bearing frictional torque | MR | 0,30 | Nm |
| Minimum diameter shaft | da min | 32 | mm |
| Number of holes in adjacent construction | na | 4 | |
| Connection thread for lubrication | M6 |
| Size of fixing screws | M6 | ||
| Pitch separation angle of holes in adjacent construction | ta | 90 | ° |
| Rib diameter inner ring | d1 | 40,50 | mm |
| Pitch circle diameter fixing holes | m | 58 | mm |
| Width of extraction slot | b | 3 | mm |
| Pitch quantity of fixing holes | n | 8 | |
| Contact angle | α | 60 | ° |
| Minimum chamfer dimension | rmin | 0,60 | mm |
| Fixing holes diameter | d2 | 6,80 | mm |
| Distance of extraction slot | I | 19 | mm |
| Pitch separation angle of fixing holes | t | 45 | ° |
