FESTO VZBA
114 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO VZBA – Ball valve. Finden Sie das passende Produkt durch Filtern mit Nominal diameter DN, Process valve connection type 1, Process valve connection type 2, Process valve connection type 3, Design type, Ventilfunktion, Flanged connection, Drive, Torque [Nm], Swivel direction, Nominal swivel angle [°], Spring ID und End-position adjustment.
VZBA Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| VZBA | VZBA- - - -63- - -V4-V4-T | Ball valve |
Typcode zur Katalognummer VZBA,
VZBA- - - -63- - -V4-V4-T
| 001 | Series |
|---|---|
| VZBA | Ball valve |
| 002 | Nominal diameter DN |
| 1/4\" | 1/4\" |
| 1/4 | 1/4\" |
| 3/8\" | 3/8\" |
| 3/8 | 3/8\" |
| 1/2\" | 1/2\" |
| 1/2 | 1/2\" |
| 3/4\" | 3/4\" |
| 3/4 | 3/4\" |
| 1 | 1\" |
| 1\" | 1\" |
| 11/4\" | 1 1/4\" |
| 11/4 | 1 1/4\" |
| 11/2\" | 1 1/2\" |
| 11/2 | 1 1/2\" |
| 2 | 2\" |
| 2\" | 2\" |
| 21/2\" | 2 1/2\" |
| 21/2 | 2 1/2\" |
| 3 | 3\" |
| 3\" | 3\" |
| 4 | 4\" |
| 4\" | 4\" |
| 003 | Process valve connection type 1 |
| G | Rp female thread |
| W | Suitable for welding |
| 004 | Process valve connection type 2 |
| G | G female thread |
| W | Suitable for welding |
| 005 | Process valve connection type 3 |
| None | |
| G | G female thread |
| 006 | Nominal pressure [bar] |
| 63 | 63 |
| 007 | Design type |
| Standard | |
| T | Three-part |
| 008 | Valve function |
| 22 | 2/2-way |
| 32L | 3/2-way, L-bore |
| 32T | 3/2-way, T-bore |
| 009 | Flanged connection |
|---|---|
| F0304 | Hole pattern 03 and 04 |
| F0405 | Hole pattern 04 and 05 |
| F0507 | Hole pattern 05 and 07 |
| F0710 | Hole pattern 07 and 10 |
| F10 | Hole pattern 10 |
| 010 | Housing material |
| V4 | Stainless steel |
| 011 | Shut-off element material |
| V4 | Stainless steel |
| 012 | Sealant |
| T | PTFE |
| 013 | Drive |
| None | |
| PP | DAPS, double-acting |
| PS | DAPS, single-acting |
| 014 | Torque [Nm] |
| None | |
| 15 | 15 |
| 30 | 30 |
| 53 | 53 |
| 60 | 60 |
| 90 | 90 |
| 106 | 106 |
| 120 | 120 |
| 180 | 180 |
| 240 | 240 |
| 015 | Swivel direction |
| None | |
| R | Right |
| 016 | Nominal swivel angle [°] |
| None | |
| 90 | 90 |
| 017 | Spring ID |
| None | |
| 4 | 4 |
| 018 | End-position adjustment |
| None | |
| C | Closed |
