FESTO VUVS
407 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO VUVS – Solenoid valve, universal. Finden Sie das passende Produkt durch Filtern mit Design principle, Baugröße, Ventilfunktion, Reset method for monostable/single solenoid valves, Pilot air, Handhilfsbetätigung, Pneumatischer Anschluss, Exhaust, Valve pilot control interface, Nominal operating voltage, Elektrischer Anschluss, EU certification und Ausführung.
VUVS Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| VUVS | VUVS-L- - - - | Solenoid valve, universal |
Typcode zur Katalognummer VUVS,
VUVS-L- - - -
| 001 | Series |
|---|---|
| VUVS | Solenoid valve, universal |
| 002 | Directional control valve type |
| L | In-line valve |
| 003 | Design principle |
| Piston spool | |
| K | Piston spool with sealing ring |
| T | Poppet valve |
| 004 | Size |
| 20 | Size 20 |
| 25 | Size 25 |
| 30 | Size 30 |
| 005 | Valve function |
| M32U | 3/2-way valve, normally open |
| T32U | 2x3/2-way valve, normally open |
| T32C | 2x3/2-way valve, normally closed |
| T32H | 2x3/2-way valve, 1x normally closed, 1x normally open |
| B52 | 5/2-way valve, double solenoid/bistable |
| M52 | 5/2-way valve, single solenoid/monostable |
| M32C | 3/2-way valve, normally closed |
| P53U | 5/3-way valve, mid-position pressurised |
| P53E | 5/3-way valve, mid-position exhausted| |
| P53C | 5/3-way valve, mid-position closed |
| 006 | Reset method for monostable/single solenoid valves |
| None | |
| A | Pneumatic spring |
| M | Mechanical spring |
| 007 | Pilot air |
| Internal | |
| Z | External |
| 008 | Manual override |
| D | Non-detenting, detenting |
| H | Non-detenting |
| S | Covered |
| 009 | Pneumatic connection |
| G18 | G1/8 |
| G14 | G1/4 |
| G38 | G3/8 |
| N18 | 1/8 NPT |
| N14 | 1/4 NPT |
| N38 | 3/8 NPT |
| Q4 | Push-in connector 4 mm |
| Q6 | Push-in connector 6 mm |
| Q8 | Push-in connector 8 mm |
| Q10 | Push-in connector 10 mm |
| Q12 | Push-in connector 12 mm |
| T38 | Push-in connector 3/8” |
| T14 | Push-in connector 1/4” |
| T12 | Push-in connector 1/2” |
| T532 | Push-in connector 5/32” |
| T516 | Push-in connector 5/16” |
| 010 | Exhaust |
|---|---|
| No fitting | |
| QN | With fitting |
| U1 | Silencer with metallic housing |
| U3 | Silencer with polymer housing |
| U5 | Sintered silencer, long |
| 011 | Valve pilot control interface |
| Standard | |
| F8 | With armature tube 8 mm, long |
| F7 | With armature tube 8 mm, short |
| FN | With armature tube 9 mm |
| 012 | Nominal operating voltage |
| None | |
| 1 | 24 V DC |
| 1A | 24 V AC/50-60 Hz |
| 3A | 230 V AC/50-60 Hz |
| 3W | 230 V AC/240 V AC/50-60 Hz |
| 5 | 12 V DC |
| 16B | 120 V AC/60 Hz and 110V AC/50-60 Hz |
| 013 | Electrical connection |
| None | |
| A1 | Plug pattern type A, to EN 175301-803 |
| B2 | Connection pattern type B, industry standard |
| C1 | Plug pattern type C, to EN 175301-803 |
| 014 | Degree of protection, electrical system |
| Standard | |
| S1 | IP65 |
| S8 | IP67 |
| 015 | EU certification |
| None | |
| EX2 | II 3GD |
| EX4 | II 2GD |
| 016 | Electrical valve accessories |
| None | |
| G | Connector socket, without LED |
| GL | Connector socket, with LED |
| GS | Connector socket, with protective circuit |
| 017 | Version |
| Expanded properties | |
| S | Focused properties |
