FESTO VOVK
16 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO VOVK – Solenoid valve. Finden Sie das passende Produkt durch Filtern mit Nominal operating voltage, Elektrischer Anschluss, Pneumatischer Anschluss und Connection direction.
VOVK Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| VOVK | VOVK-B-T-6-M32C-M-N- - -P- - | Solenoid valve |
Typcode zur Katalognummer VOVK,
VOVK-B-T-6-M32C-M-N- - -P- -
| 001 | Series |
|---|---|
| VOVK | Solenoid valve |
| 002 | Type of directional control valve |
| B | Sub-base valve |
| 003 | Design principle |
| T | Poppet valve |
| 004 | Size |
| 6 | Size 6 |
| 005 | Valve function |
| M32C | 3/2-way valve, normally closed |
| 006 | Reset method for single solenoid valves |
| M | Mechanical spring |
| 007 | Pilot air |
| N | None |
| 008 | Nominal operating voltage |
| 1 | 24 V DC |
| 5 | 12 V DC |
| 009 | Electrical connection |
|---|---|
| H5Z | Plug pattern H5Z |
| T1 | Pin |
| 010 | Circuitry |
| P | Protective circuit |
| 011 | Pneumatic connection |
| F | Flange/sub-base |
| B3 | Barbed connector, 3 mm |
| B3.2 | Barbed connector, 3.2 mm |
| 012 | Connection direction |
| F | Front |
| B | Underneath |
